Reference Design : Exterior Wall Packs

Luminaire Specifications:
Luminaire Watts: 55W (70 CRI, 4000K)
Luminaire Lumens : 7500 Lumens
Luminaire Model GE EWAS01 C4AF740
Roadway Classification Type IV
Longitudinal Classification Short
Luminaire Efficacy Rating (LER) 134
Maximum UGR 40.1
BUG Rating B1-U0-G2
